Embedded MXM 3.1 Type A Module with Intel® Arc™ A370/A350 GPU


  • Intel® Arc™ A370M/A350M Embedded GPU, up to 8 Xe-cores
  • 4GB GDDR6 Memory
  • PCIe 4.0 [x8] Interface
  • DP++ 1.4/HDMI 2.1 x 4
  • Standard MXM 3.1 Type A form factor
  • OpenCL™/OpenGL®/oneAPI/Direct X12/Ray Tracing Support

The MXM-ACMA introduces the MXM 3.1 Type A GPU module form factor to the AAEON lineup, offering potent, efficient graphics acceleration powered by Intel® Arc™ A-Series graphics.

Equipped with 4GB of GDDR6 memory, ray tracing, and Intel® Deep Link Technologies, the MXM-ACMA expedites data handling and optimizes rendering capabilities for a variety of embedded solutions, such as digital signage, gaming, edge AI, and healthcare imaging.

A Compute Boost for Heavy AI Workloads

With a choice of Intel® Arc™ A370M or Intel® Arc™ A350M GPUs, the MXM-ACMA can harness up to 128 Intel® Xe Matrix Extension (Intel® XMX) engines across up to eight Xe-cores to substantially boost compute power for AI workloads. Meanwhile, its ray tracing technology accelerates the training and inference processes of machine learning models.

Offering quadruple display outputs in the form of either DP++ 1.4 or HDMI 2.1 interfaces, the MXM-ACMA offers a greater variety of visual setup options. Be it for multi-screen digital signage installations or powering interactive gaming environments, the MXM-ACMA guarantees seamless connectivity and stunning visuals.

Designed for Longevity | MXM-ACMA

Suited to embedded deployments in digital signage, casino gaming, and edge AI, the MXM-ACMA is built to last, as illustrated by both its industrial temperature range and broad OS compatibility. The module also supports a variety of open-source, cross-platform development tools including OpenCL™, OpenGL®, OpenVINO™, and DirectX 12 Ultimate, for limitless development potential.



Form Factor Standard MXM 3.1 Type A form factor

Intel® Arc™ A370M GPU (8 Xe-cores, TGP 35W)
Intel® Arc™ A350M GPU (6 Xe-cores, TGP 25W)

Memory 4GB GDDR6, 64-bit , Bandwith 112GB/s
Display Interface DP++ 1.4 x 4 or HDMI 2.1 x 4
Dimension 3.2“ x 2.7“ (82mm x 70mm)
Power Consumption

Intel® Arc™ A370M GPU, TGP 35W
Intel® Arc™ A350M GPU, TGP 25W

Operating Temperature 32°F ~ 140°F (0°C ~ 60°C) in 0.5m/sec airflow
Storage Temperature -40°F ~ 185°F (-40°C ~ 85°C)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
OS Support

Windows 10 (64bit) / Windows 11
Ubuntu 22.04 LTS

Others OpenCL™ 4.6/OpenGL® 3.0/oneAPI/DirectX 12 Ultimate/Ray Tracing Support
For packing list, detailed specifications and other product information, download the Datasheet or User Manual.
