BOXER-8240AIは、NVIDIA® Jetson AGX Xavier™を搭載し、産業用の頑丈なデザインが特徴です。これにより、開発者は必要な場所にAIエッジアプリケーションをさらに持ち込むことができます。
BOXER-8240AIの中核は、革新的でパワフルなNVIDIA Jetson AGX Xavierです。この製品には、驚異的な512基のCUDAコアと64基のTensorコアを搭載したVolta GPUが搭載されており、最大32 TOPSのAI処理速度を提供します。AGX Xavierには複数の電力モードが搭載されており、開発者やユーザーはシステムを自分たちのニーズに合わせて調整することができます。それにより、より効率的な電力利用やパフォーマンスの最大化が可能です。
また、BOXER-8240AIは革新的なファンレス設計で構築されており、Jetson AGX Xavier SoCが-10°Cから55°Cの周囲温度で動作し、パフォーマンスを損なうことなく、同時にダストやその他の汚染物を防ぎます。
BOXER-8240AIは、AI、制御、および通信を1つのプラットフォームソリューションに統合するよう設計されています。柔軟なI/O機能を備えており、その中には4つのPoEギガビットイーサネットポートが含まれています。これらはそれぞれ1 Gbpsの速度を提供し、接続されたカメラに電力を供給しながら、リアルタイムのビデオ処理のための遅延のないストリーミングを確保します。
BOXER-8240AIには、40ピンのI/Oコネクタ、デュアルCOM RS-485ポート、USB3.2 Gen 1およびUSB2.0 Type Aポート、2つのUSB3.2 Gen 1 Type Cポート、そしてオーディオラインイン（マイク）およびオーディオラインアウトポートも搭載されています。
BOXER-8240AIは、M.2 2230 E-keyスロットを利用してWi-Fiなどの無線通信を含む拡張性を提供し、強力なエッジネットワークゲートウェイとして展開することができます。さらに、M.2 2280 NVMeスロットとSATA III（6.0 Gbps）ストレージを備え、システムの底部にはアクセスパネルがあり、簡単にインストールすることができます。
このAI、制御、通信の組み合わせにより、BOXER-8240AIはさまざまなアプリケーションで活躍します。例えば、スマートファクトリーロボットのAGVパスファインディングや衝突回避などの単一の高度なタスクを支援する場合、または健康要件の遵守のためのインテリジェントセキュリティや人群監視において複数のAI推論を並行して実行し、広範なカバレッジを提供する場合などに最適です。
BOXER-8240AI
AI@Edge Fanless Embedded Box PC with NVIDIA AGX Xavier
Features
- 512-core Volta GPU with Tensor Cores
- Support RJ-45 x 4 for PoE (802.3af, total 60W)
- Support DB-9 x 1 for RS-232/422/485, CANBUS x 1
- Support 40-pin header, Mic in and Line out
- Supoort M.2 E key, M key and SATA storage
Accelerated AI Inferencing with the NVIDIA® Jetson AGX Xavier™
Powered by the NVIDIA® Jetson AGX Xavier™, the BOXER-8240AI can take advantage of its NVIDIA Volta™ GPU architecture, containing 512 CUDA® cores and 64 Tensor cores to provide a peak AI performance of 32 TOPS.
Such exceptional performance enables the BOXER-8240AI to process and analyze several high-resolution images simultaneously, offering precise attributes for implementing traffic management and intelligent security applications.
Unique I/O for Real-Time Data Processing
With a flexible I/O featuring four PoE Gigabit Ethernet ports and a 40-pin programmable GPIO, the BOXER-8240AI is designed to accommodate a wide range of sensors and cameras. Consequently, vision-based applications benefit from no latency, facilitating deployment in applications such as smart factory AGVs or in-vehicle collision avoidance systems.
The BOXER-8240AI also hosts a myriad of expansion options, such as an M.2 2230 E-key slot, enabling Wi-Fi, and an M.2 2280 NVMe slot and SATA III (6.0 Gbps), offering a platform for aerospace and autonomous robotics solutions.
Rugged Mechanism Design for Dynamic Functionality
The BOXER-8240AI’s fanless design offers users an incredibly durable and adaptable machine. A wide operating temperature, along with anti-shock and anti-vibration features enable the BOXER-8240AI to be deployed in a variety of environments, from unstable and dynamic settings to Edge Network Gateway applications.
Illustrating AAEON’s commitment to the needs of our customers is the customization options available through the BOXER-8240AI’s clamshell chassis, allowing for simplified disassembly and module expansion.
Software Integration to Enhance Security and Speed up Time to Market
Pre-installed with a Linux OS, the BOXER-8240AI also supports Secure Boot to ensure data security complies with the industry standard. Additionally, Trust zone cybersecurity measures are also supported to provide robust protection, ensuring the comprehensive integrity of data processed on the edge.
For fast and easy application development, AAEON’s customized Linux OS supports a variety of AI frameworks, enabling inference models to be added to suit the project
×
【2022 Best Choice Award Golden Award】BOXER 8240AI｜Embedded Edge
The BOXER-8240AI won its second award of the year during COMPUTEX TAIPEI, Asia’s largest annual ICT exhibition, being presented with the Golden Award in the Smart Retail Business Solution & IPC Embedded Products category of the COMPUTEX Best Choice Award.
Out of thousands of products, only six were selected for the Golden Award at this year’s exhibition, illustrating AAEON’s esteemed place within the industry, and recognition of its continued commitment to innovation.
2022 has also seen the BOXER-8240AI win AAEON another Taiwan Excellence Award, which recognized its aesthetic clamshell design, software integration, and the eclectic application potential that its unique I/O provides users.
The BOXER-8240AI’s synthesis of refined edge AI inferencing, unique I/O features, and fanless mechanism design makes it the superior choice for any vertical market application, from intelligent security to industry 4.0.
SYSTEM | |
| AI ACCELERATOR | NVIDIA® AGX Xavier |
| CPU | 8-core ARM v8.2 64bit CPU, 8MB L2 + 4MB L3 |
| SYSTEM MEMORY | 32GB 256-Bit LPDDR4x 137GB/s |
| STORAGE DEVICE | 32GB eMMC 5.1 |
| DISPLAY INTERFACE | HDMI 2.0 x 1 |
| ETHERNET | 10/100/1000 Base-TX with IEEE 802.3af PoE LAN x 4 |
| I/O | PoE x 4 (IEEE 802.3af, total 60W) |
| EXPANSION | USB 2.0 header x 1 (Optional, circuit reserved) |
| INDICATOR | Power LED x1 |
| OS SUPPORT | Linux (NVIDIA Jetpack 4.5 and above) |
POWER SUPPLY | |
| POWER REQUIREMENT | DC 12V~24V 2-pin terminal |
MECHANICAL | |
| MOUNTING | Wallmount |
| DIMENSION | 8.26” x 6.46” x 2.32” (210mm x 164.2mm x 59mm) |
| GROSS WEIGHT | 6 lbs (2.72kg) |
| NET WEIGHT | 4.23 lbs (1.92kg) |
ENVIRONMENTAL | |
| OPERATING TEMPERATURE | 14°F ~ 131°F (-10°C ~ 55°C, according to IEC60068-2 with 0.5 m/s AirFlow) |
| STORAGE TEMPERATURE | -40 °F ~ 158°F(-40°C ~ 70°C) |
| STORAGE HUMIDITY | 95% @ 40°C, non-condensing |
| ANTI-VIBRATION | Random, 3 Grms, 5 ~ 500Hz |
| CERTIFICATION | CE/FCC Class A |
