AI@Edge Fanless Embedded Box PC with NVIDIA Jetson TX2, CANbus x 1


  • NVIDIA Jetson TX2
  • Support AAEON ACLinux 4.9, Compliance with Ubuntu 18.04
  • 8GB LPDDR4, 32GB eMMC 5.1
  • HMP Dual Denver 2 + Quad ARM A57
  • HDMI 2.0 x 1, USB 3.2 Gen 1 x 2
  • RS-232 x 1, CANBUS x 2 Channel
  • OTG x 1/LAN x 1/MicroSD x 1

The BOXER-8110AI is fitted with the NVIDIA Jetson TX2, it supports 256 CUDA cores and a range of AI frameworks including Tensorflow, Caffe2, and Mxnet, and in addition, users can install the device with their own AI inference software. These features make the BOXER-8110AI perfect for edge AI applications.

The BOXER-8110AI’s CANbus and rugged design features (anti-dust measures, aluminum chassis, wide operating temperature range) mean it can support industrial automation and in-vehicle applications. With its powerful processor and cost-effective design, this is one AI platform you’ll be able to install anywhere.



AI Accelerator Nvidia Jetson TX2
CPU HMP Dual Denver 2 + Quad ARM A57
System Memory 8GB LPDDR4
Storage Device 32GB eMMC 5.1,MicroSD
Display Interface HDMI 2.0
Ethernet 10/100/1000 Base-TX x 1
I/O USB 3.2 Gen 1 x 2 HDMI x 1 LAN x 1 MicroSD x 1 OTG x 1 Antenna Hole x 1 DC Power Input x 1 2 channel CANBUS x 1 DB-9 RS-232 x 1
OS Support AAEON ACLinux 4.9, Compliance with Ubantu 18.04

Power Supply

Power Requirement 12V with 2-pin terminal block


Mounting Wallmount
Dimensions (W x H x D) 4.33” x 1.57” x 2.56” (110mm x 40mm x 65mm)
Gross Weight 2.20 lb (1 kg)
Net Weight 1.10 lb (0.5 kg)


Operating Temperature -4°F ~122°F (-20°C ~ 50°C, according to IEC60068-2 with 0.5 m/s AirFlow; with Industrial Device)
Storage Temperature -49°F ~176°F (-45°C ~ 80°C)
Storage Humidity 95% @ 40°C, non-condensing
Anti-Vibration 3 Grms/ 5 ~ 500Hz/ operation – eMMC
Certification CE/FCC class A
For packing list, detailed specifications and other product information, download the Datasheet or User Manual.
