BOXER-8222AI | Fanless Embedded Box PC with NVIDIA Jetson Nano


AI@Edge Compact Fanless Embedded AI System with NVIDIA® Jetson Orin Nano™


  • NVIDIA® Jetson Orin Nano™
  • GbE PoE/PSE 802.3af/at x 4 + GbE LAN x 1
  • M.2 2230 E-Key x 1, M.2 2280 M-Key x 1, M.2 3042/3052 B-Key x 1
  • Operating Temperature: -15°C ~ 65°C

Introducing the BOXER-8623AI, a powerful addition to AAEON’s AI system range featuring the Jetson Orin Nano™. Equipped with the perfect blend of environmentally robust hardware and elegant interfaces, the duo are this year’s standouts when it comes to bringing dynamic AI functionality to the edge, from standalone smart city solutions to integrated industrial deployment.

Boasting four PoE LAN ports, environmental resilience, and an expansive selection of interfaces, the BOXER-8623AI are as robust and reliable as they are technologically innovative.



AI Accelerator NVIDIA® Jetson Orin Nano™
CPU 6-core Arm® Cortex®-A78AE ARMv8.2 64-bit CPU
System Memory


Storage Device M.2 2280 M Key x 1
Display Interface HDMI 1.4 (Type-A) x 1

RJ-45 x 1 for GbE LAN
RJ-45 x 4 for GbE PoE/PSE 802.3af/at (Max.60W)


USB 3.2 Gen 2 (Type-A) x 4
DB-9 x 1 for RS-232 (Rx/Tx/CTS/RTS) x 1 and CANBus FD x 1
DB-15 x 1 for RS-232(Rx/Tx)/422/485 x 1 and DIO x 8
Micro USB x 1 for OS Flash
Power Button x 1
Recovery Button x 1
Antenna Hole x 6


M.2 2280 M-Key x 1 (NVMe)
M.2 3042/3052 B-Key x 1
M.2 2230 E-Key x 1
SIM Slot x 1

Indicator Power LED x 1
OS Support

Linux (NVIDIA Jetpack™ 5.0 and up)

Power Supply

Power Requirement 12V ~ 24V DC in with 2-pin Terminal Block x 1


Mounting Wall Mount
Dimensions (W x D x H)

7.09” x 5.35” x 2.95” (180mm x 136mm x 75mm)

Gross Weight 7.7 lb (3.5kg)
Net Weight 5.5 lb (2.5kg)


Operating Temperature

5°F ~ 149°F (-15°C ~ 65°C), according to IEC60068-2 with 0.5 m/s AirFlow

Storage Temperature -40°F ~ 185°F (-40°C ~ 85°C)
Storage Humidity 5% ~ 95% @ 40°C, non-condensing
Anti-Vibration 3.5Grm / 5~500Hz / Operation
Anti-Shock 50G peak acceleration
Certification CE/FCC class A
For packing list, detailed specifications and other product information, download the Datasheet or User Manual.
