UP Xtreme i14
UP Xtreme i14开发板, 基于Intel® Core™ Ultra 5/7处理器
功能特点
- Intel® Core™ Ultra 5/7处理器
- 板载双通道LPDDR5 6400, 最高支持64GB
- 最高支持同步四显
- M.2 2280 M-Key x 2
- M.2 3052 B-Key x 1 (5G)
- M.2 2230 E-Key x 1 (Wi-Fi/BT)
- 2.5GbE x 1, GbE x 1
- USB 3.2 Gen 2 (Type A x 2, Type C x 1)
- 板载TPM 2.0
- 宽幅直流输入9-36V
The UP Xtreme i14 introduces the new Intel® Core™ Ultra processor platform to the AAEON catalog, benefiting from a new high-performance CPU core architecture and onboard LPDDR5. This combination enables the board to execute heavy task loads and real-time data processing with ease. The chip’s integrated CPU, GPU, and NPU provide up to 32 TOPS for advanced industrial robotics, frictionless retail, and smart healthcare, while also maintaining power efficiency. AAEON also institutes power limitations via CPU frequency scaling to maintain the stability of the board’s CPU temperature and voltage during operation.
A total of four M.2 Keys support Wi-Fi, 5G, and AI acceleration module installation. Further, a plethora of interfaces suitable for a range of embedded markets, including a 40-pin GPIO, multiple LAN and USB ports, and a serial port header, offer the necessary peripheral support to develop advanced AMR and frictionless retail solutions. Additionally, a broad 9V-36V power input range facilitates the board’s deployment in industrial control settings.
The UP Xtreme i14’s ability to capture and process visual data, combined with the quality of its display outputs, is industry-leading. The board’s dual MIPI camera support provides higher resolution image acquisition for real-time edge processing. A total of two HDMI 2.1 ports, DP 2.1, and one DP 1.4 via USB Type-C are all capable of achieving 8K resolution at 60Hz, leverage IntelR Arc? graphics to deliver crystal clear imaging for AI-assisted healthcare imaging, smart retail signage, and POS solutions.
System | |
| Processor | Intel® Core™ Ultra 5/7 Processors: |
| Graphics | Intel® Arc™ graphics |
| Memory | Up to 64GB onboard LPDDR5 (Dual-Channel) |
| Storage | M.2 2280 M-Key x 2 |
| I/O | HDMI 2.1 x 2 |
| Camera | MIPI-CSI via 61-Pin FPC Connector x 1 |
| USB | USB 2.0 x 2 (from 10 pin header x 1) |
| Expansion | 40-pin GPIO x 1 |
| Display Interface | HDMI 2.1 x 2 |
| Ethernet | 2.5GbE x 1 (via Intel® Ethernet Controller I226-IT), GbE x 1 (Intel® Ethernet Connection I219) |
| Security | Onboard TPM 2.0 |
| RTC | Yes |
| OS Support | Windows 10/11 (64bit) |
Power Requirement | |
| Power | 9-36V DC-in (Lockable plug) |
| Power Supply Type | AT/ATX (ATX as default) |
| Power Consumption (Typical) | TBD |
Mechanical | |
| Dimension | 4.74“ x 4.82“ (120.35mm x 122.5mm) |
| Net Weight | 12.7 lb. (0.36Kg) |
| Gross Weight | TBD |
Environment | |
| Operating Temperature | With Cooler: 32°F ~ 140°F (0°C ~ 60°C), 0.5m/s airflow |
| Operation Humidity | 0% ~ 90% relative humidity, non-condensing |
| MTBF | TBD |
| Certification | CE/FCC Class A, RoHS Compliant, REACH |
