ZEUS-PUR0

4U Rackmount Purley Platform Server System, Support Xeon® FPGA CPU

フィーチャ

  • Dual Intel® Xeon® Processor Skylake-SP and Cascade Lake –SP processor. Intel® Communications Chipset C621
  • DDR4 2133/2400/2666 MHz DIMM (8 DIMM Per CPU) RDIMM x 16, Up to 512 GB
  • Up to 32 Gigabit Ethernet Ports Via NIM (Project Base Up to 32 Gigabit Ethernet Ports Via NIM)
  • 6 x 3.5“ SATA HDD or 2.5“ SATA HDD x 6, M.2 2260 Socket x 1
  • Option Rear Side PCIe [x4] x 4 (or PCIe [x8] x 2) + PCIe [x8] x 2 (Or PCIe [x16] x 1). Option Front PCIe [x16] x 2. Optional Parallel LCM with Keypad x 1. RJ-45 Console x 1, USB 3.0 x 2, 1 GbE LAN x 2
  • 800~1600W CRPS Redundant Power. IPMI Support
概要

ZEUS-PUR0 AI エッジ サーバーは、マルチアクセス エッジ コンピューティング (MEC) からスマート シティに至るまで、または単一プラットフォームでの施設全体のスマート監視の提供に至るまで、要求の厳しいさまざまな AI アプリケーションを強化する高性能 AI コンピューティングを提供します。

ZEUS-PUR0 は、プロジェクトに統合するための最大限の拡張性と柔軟性を提供するように設計された 4U シャーシに構築された 2 つの第 2 世代インテル® Xeon® スケーラブル プロセッサー (旧名 Cascade Lake) を搭載しています。

十分なスペースと革新的な熱設計により、NVIDIA RTX 2080 Ti などの最大 4 台の PCIe [x16] デバイスの導入が可能になり、合計 56 TFLOPS を超える処理能力を供給します。あるいは、ZEUS-PUR0 は、AAEON の AI Core XP8 PCIe [x4] カードを最大 6 枚サポートでき、それぞれに最大 8 つの Intel® Movidius® Myriad™ X VPU が搭載されます。これにより、ZEUS-PUR0 は複数の AI プロセスを並行して処理したり、より広範囲の入力にわたって同じ推論を処理したりできるようになります。

仕様
ZEUS-PUR0

System

Form Factor 4U Rackmount Server System
Processor Intel® Xeon® Skylake-SP and Cascade Lake-SP Processors
System Memory DDR4 2133/2400/2666 R-DIMM, Up to 512 GB
Chipset Intel® C621
Ethernet Intel® i211 Gigabit Ethernet x 2
Bypass Depend on NIM module
BIOS AMI BIOS
Serial ATA SATA II port x 6
Storage 2.5” HDD x 6 or 3.5” HDD x 6, M.2 x 1
Expansion Interface

NIM slot x 4 (Project Base NIM Slot x 8)
Option front PCIe [x16] slots x 2
Option rear side PCIe [x4] x 4 (or PCIe [x8] x 2) + PCIe [x8] x 2 (Or PCIe [x16] x 1)
M.2 Slot x 1
Mini PCIe x 1

Watchdog Timer 1~255 steps by software programmable
RTC Internal RTC
System Fan 5
Front I/O Panel Power LED x 1, Status LED x 1, HDD Active LED x 1
Rear I/O Panel

AC Power Input x 1, Power Switch x 1, VGA port (Optional), Rear Expansion Slot (Option)

Color Black
Power Supply 800 ~1600W Redundant PSU
Dimension (480mm x 600mm x 176mm)
Power Consumption TBD
MTBF (Hours) TBD

Display

Chipset Intel® C621
Graphic Engine From IPMI or Mini PCIE Option
Resolution
Connector VGA Option

I/O

Serial Port RJ-45 Console x 1
K/B and Mouse N/A
USB USB 3.0 x 2

Environmental

Operating Temperature 32°F ~ 104°F (0°C ~ 40°C )
Storage Temperature -4°F ~ 140°F (-20°C ~ 60°C)
Operating Humidity 10% ~ 80% relative humidity, non-condensing
Storage Humidity 10% ~ 80% @40°C; non-condensing
Vibration

0.5 g rms/ 5 ~ 500Hz / operation (2.5” Hard Disk Drive)
1.5 g rms/ 5 ~ 500Hz / non operation

Shock

10 G peak acceleration (11 m sec. duration), operation
20 G peak acceleration (11 m sec. duration), non operation

ダウンロード
パッキングリスト、詳細仕様、その他の製品情報については、データセットまたはユーザーマニュアルをダウンロードしてください。
